Y STRAINER FLANGE RF ANSI CLASS 150

JUAL Y STRAINER ANSI 150 WCB FLANGE RF
Kode
ITM00497
Merk
EVO

Deskripsi Produk

JUAL Y STRAINER ANSI 150 WCB FLANGE RF

SIZE : 1/2" - 24" or Custom 26" - 48"
FACE TO FACE LENGTH: ASME / ANSI B16.10
CONNECTIONS & DIMENSIONS: ASME / ANSI B16.5, ASME / ANSI B 16.25
FLANGES: RF ANSI #150
PRESSURE & TEMPERATURE: ASME / ANSI B16.34
MANUFACTURE : CHINA


MATERIAL
BODY-COVER : CAST STEEL A216WCB, GP240GH+N
SCREEN : STAINLESS STEEL AISI 304
GASKET : GRAPHITE
DRAIN PLUG : FORGED STEEL A105
BOLTS : A 193 GR. B7
NUTS : A 194 GR. 2H
