FORGED FITTING STAINLESS STEEL

Half Coupling Socket Weld Stainless Steel
Half Coupling Socket Weld Stainless Steel

HALF COUPLING SOCKET WELD STAINLESS STEEL

FORGED SOCKET WELD HALF COUPLING STAINLESS STEEL, SOCKET WELD HALF COUPLING PIPE FITTING, HALF COUPLING SOCKET WELD SS304 SS316 STAINLESS STEEL, CLASS 3000 LBS, 6000 LBS, 9000 LBS
Kode
ITM00389
Merk
TAIWAN

Deskripsi Produk

JUAL FORGED SOCKET WELD HALF COUPLING STAINLESS STEEL, SOCKET WELD HALF COUPLING PIPE FITTING, HALF COUPLING SOCKET WELD SS304 SS316  STAINLESS STEEL CLASS 3000 LBS, 6000 LBS, 9000 LBS

STANDARD :  ASME B16.11 , MSS SP-79, MSS SP-95, 83, 95, 97, BS3799
                       DIN 2065, DIN 2615, DIN 2616, DIN 2617, DIN 28011
                       EN 10253-1, EN 10253-2
SIZE : 1/8 INCH - 4 INCH
PRESSURE CLASS : 3000 LBS, 6000 LBS, 9000 LBS
CONNECTION : SOCKET WELD
GRADE : ASTM /  ASME A/SA182-F304 / L, 304H, 309S, 309H, 310S, 310H, 316, 316H, 316L, 316LN, 317, 317L, 321, 321H, 347, 347H, 904L
MANUFACTURED : TAIWAN, EROPA, AMERIKA, JEPANG, KOREA
