Deskripsi Produk
FORGED SOCKET WELD ELBOW 45 90 DEGREE STAINLESS STEEL, SOCKET WELD ELBOW 45 90 DEGREE PIPE FITTING, FULL ELBOW 45 90 DEGREE SOCKET WELD SS304 SS316 STAINLESS STEEL CLASS 3000 LBS, 6000 LBS, 9000 LBS
STANDARD : ASME B16.11 , MSS SP-79, MSS SP-95, 83, 95, 97, BS3799
DIN 2065, DIN 2615, DIN 2616, DIN 2617, DIN 28011
EN 10253-1, EN 10253-2
SIZE : 1/8 INCH - 4 INCH
PRESSURE CLASS : 3000 LBS, 6000 LBS, 9000 LBS
CONNECTION : SOCKET WELD
GRADE : ASTM / ASME A/SA182-F304 / L, 304H, 309S, 309H, 310S, 310H, 316, 316H, 316L, 316LN, 317, 317L, 321, 321H, 347, 347H, 904L
MANUFACTURED : TAIWAN, EROPA, AMERIKA, JEPANG, KOREA
